CAMECA Helps US Navy LEAP Forward in Materials Design

publication date: Sep 18, 2015
 |
author/source: CAMECA

CAMECA Delivers Local Electrode Atom Probe (LEAP) To US Naval Research Laboratory for Advanced Materials Development

Electrode Atom Probe (LEAP)The US Naval Research Laboratory (NRL) has taken delivery of the US Department of Defense’s first Local Electrode Atom Probe (LEAP) microscope. The high- performance atom probe from CAMECA, a unit of AMETEK Materials Analysis, is used in advanced materials analysis to provide precise atom-by-atom identification, 3-D spatial positioning, and accurate atomic-scale reconstruction of a material’s microstructure. Since their development in the 1960s, atom probes have contributed to major advances in materials science.

“The exact knowledge of where individual atoms are in a material is of tremendous benefit when engineering new materials,” notes Keith Knipling of the NRL Materials Science and Technology Division. “We expect the LEAP to greatly enhance our ability to develop new materials, including the next generation of structural alloys for stronger ship hulls and more advanced turbine engines, new electronic materials for tomorrow’s faster integrated circuits, and advanced solar cell and battery materials with improved power and energy efficiency.”

LEAP operates on the principle of field evaporation, whereby a strong electric field applied to a specimen is sufficient to cause removal of atoms by ionization. Proprietary single-particle detection enables isotopic identification by time-of-flight mass spectrometry and positional determination.

CAMECA’s LEAP system offers high data quality as well as improved ease of use via prefabricated Microtip™ specimen carriers, which permit multiple samples to be prepared, mounted and loaded into the instrument for maximum efficiency for multi-experiment scenarios.

Atom evaporation is triggered either by a voltage or laser pulse applied to the sample. The resulting ions are accelerated away from the sample and identified. By repeating the sequence thousands of times per second, atoms are progressively removed from the sample tip and a 3D atomic-scale image of the material can be reconstructed.

“Mapping the location of each chemical species in a material microstructure enables an unprecedented understanding of the true effects of alloying and material synthesis, which is essentially for truly optimizing the properties of any material. We expect LEAP to deliver new atomic-scale perspectives and insights into a wide range of materials science investigations.”

Researchers at NRL, for example, are developing semiconductor materials with very dilute levels of added “dopant” atoms for the purpose of tailoring their electrical properties. These doped materials form the building blocks of nearly all semiconductor electronic devices, such as diodes, transistors, solar cells, light-emitting diodes and integrated circuits.

“Most analytical technical are incapable of measuring these low concentration levels, much less where the dopants are segregated within the microstructure. With LEAP, our researchers can now answer those questions,” adds Knipling.

CAMECA pioneered the development of atom probe tomography. Among its most recent advancements is the LEAP 5000, which sets the industry standard in terms of analytical accuracy, sensitivity, and 3D spatial resolution across a wide variety of metals, semiconductors and insulators and achieves an atom-by-atom identification efficiency of 80%.

About the US Naval Research Laboratory

The US Naval Laboratory is the US Navy’s full-spectrum corporate laboratory, conducting a broadly based multidisciplinary program of scientific research and advanced technological development. The laboratory, which has served the US Navy for more than 90 years, continues to meet the complex technological challenges of today’s world. More information is available at www.nrl.navy

About CAMECA

CAMECA® has more than 60 years of experience in the design, manufacture and servicing of scientific instruments for material micro- and nano-analysis. Since pioneering Electron Probe Microanalysis (EPMA) instrumentation in the 1950s and Secondary Ion Mass Spectrometry (SIMS) in the 1960s, CAMECA has remained an undisputed world leader, while achieving numerous breakthrough innovations in such complementary techniques as Low-energy Electron-induced X-ray Emission Spectrometry (LEXES) and Atom Probe Tomography (APT).

Headquartered near Paris, CAMECA also has a production facility in Madison WI, USA where the LEAP APT is designed and manufactured, further locations in Brazil, China, England, Germany, India, Japan, Korea, and Taiwan. CAMECA is a business unit of the Materials Analysis Division of AMETEK® Inc., a leading global manufacturer of electronic instruments and electromechanical products.
